Industrial VRLA Battery

FT12-55 12V55AH

Front Terminal 12V55AH Lead acid battery

  • Battery Model: FT12-55 / 12V55AH
  • Dimension: 291*106*230mm
  • Battery Weight: 18KG
  • Application: Telecom /Solar power system etc
  • FT Battery Voltage Range:12V
  • FT Battery Capacity Range: 55AH-200AH
  • OEM:Accepted
  • Lead time: 2-3 Weeks
  • Shipping port:Shenzhen /Shanghai etc

Description & Features


Yotano Front terminal battery design allows for easier and more convenient access to the terminals, making it simpler to connect and disconnect cables without having to remove the entire battery from its enclosure or rack.

Front terminal batteries are commonly used in applications where space is limited or when there are specific requirements for easy accessibility, such as telecommunications systems, uninterruptible power supplies (UPS), and data centers, Emergency lighting system.


  1. Standard structure design suitable for 19-inch and 23-inch battery cabinets, and a narrow and high structure with good heat dissipation performance
  2. Adsorbed glass fiber separators, with a gas recombination efficiency of 99%, removing the need for replenishment
  3. Extremely low self-discharge, allowing for a long rest period
  4. Computer aided design and lead-calcium-tin ally grids, suitable for high-power discharge
  5. Unique handle structure, facilitating handling and installation


Industrial VRLA Battery – Front Terminal Series

Industrial VRLA Battery-Front Terminal Series
ModelRated VoltageRated CapacityTerminalBattery Dimension(mm)Weight (KGS)Spec
(V)(AH)LengthWidthHeightTotal Height±3%PDF
FT12-5512V55 AHM627710623123116.0 KGView
FT12-7512V75 AHM656111518718723.5 KGView
FT12-10012V100 AHM839411028528530.8 KGView
FT12-100C12V100 AHM840911029529531.0 KGView
FT12-10512V105 AHM850711023123130.5 KGView
FT12-105F12V105 AHM840711022323830.0 KGView
FT12-15012V150 AHM855111028728745.5 KGView
FT12-15512V155 AHM855111028728748.0 KGView
FT12-18012V180 AHM856012531631654.0 KGView
FT12-20012V200 AHM856012531631658.0 KGView
